DOUBLE COUNTER-BALANCE VALVES cw SIGNAL RESTRICTOR

VODL/V1516 Series

Steel body

The 1516 series is built with zinc plated steel bodies to ensure a top level of strength and durability, these valves can reach a work pressure of 400 bar. All valves in the range are equiped with pilot signal restrictors to ensure smooth and safe operation in every load handling application

V1516 series - As per N1516 but is insensitive to back pressure on D1or D2 in return mode.
